Generic Type Aliphatic Acrylic Polyurethane

Description

Thin film, high gloss finish with exceptional weathering performance characteristics. Used
extensively in virtually all industrial markets, 134 HG provides a smooth, durable finish that has
superior resistance to corrosion, abrasion and chemical exposure.

Features

• High solids, low VOC content
• Excellent weatherability
• Exceeds SSPC Paint 36 specification for a Level 3 urethane
• Available in all Carboline colors including metallic-pigmented colors
• Excellent flow characteristics allow for application by spray or roller
• Superior impact and abrasion resistance
• Indefinite recoatability
• VOC compliant to current AIM regulations
• Meets the requirements of AWWA D 102 Outside Coating System (OCS) 5 & 6
• Suitable for use in USDA inspected facilities
• Meets the performance requirements of MIL-PRF-85285E Type II, Class H Polyurethane
• Meets the performance requirements of UFGS 09 97 13.27 Polyurethane Topcoat

Color
1864 (White), S800 (White), 6666 (Safety Yellow), 1675 (Ignition Yellow), 5555 (Safety Red), C703
(Grey), C705 (Light Grey), C900 (Black). Other colors are available on request. Contact your
Carboline Representative for availability
Finish Gloss

Primer Refer to Substrates & Surface Preparation.

Dry Film Thickness 2 – 3 mils (51 – 76 microns) per coat

Solids Content By Volume 70% +/- 2%

Theoretical Coverage
Rate
1123 ft2/gal at 1.0 mils (27.6 m2/l at 25 microns)
561 ft2/gal at 2.0 mils (13.8 m2/l at 50 microns)
374 ft2/gal at 3.0 mils (9.2 m2/l at 75 microns)
Allow for loss in mixing and application.

VOC Values

As Supplied : 2.2 lbs./gal (264 g/l)
Thinner 214 : 25 oz/gal 2.9 lbs./gal (348 g/l)
Thinner 215 : 25 oz/gal 3.0 lbs./gal (362 g/l)
Thinner 72 : 25 oz/gal 3.05 lbs./gal. (366 g/l)
Thinner 25 : 25 oz/gal 3.06 lbs./gal (366 g/l)
These are nominal values and may vary slightly with color.

Dry Temp. Resistance

Continuous: 300°F (149°C)
Some discoloration and loss of gloss may be experienced at elevated temperatures.

Topcoats Carbothane® 134 Clear Coat if required.
